The air conditioner production line consists of the assembly line, vacuum line, and testing line. Assembly line conveyor type can be slat chain conveyor, double speed plus chain conveyor, vacuum line and the testing line is car table circle conveyor type. Specification
| W800mm slat chain conveyor | 490X750MM | Support feet | 40*80*2mm aluminum profile |
| Guide rail | 440*210*3.0mm thick special used aluminum with an A3 sheet | Slat chain | 2.0mm thick stainless steel sheet folded, L800*W96*H20mm |
| Chain | 50.8mm single ear big roller with the side chain | Foot cup | M16X80 adjustable galvanized foot cup |
| Wire slot | 80*80*1.2 galvanized sheet folded, with sockets | wire and socket | three holes socket and GB4 square wire |
| Power part | 18m/set,17m/set | Machine head/tail | 50*50*2.0mm iron tube welded |
| Motor | 2HP1:100(Taiwan CPG) | Lighting Structure Part | 30 m |
| Illumination | LED lamp | Instruction board | H type thicken aluminum,A4 Acrylic board |
| Air pipe | 3/4"galvanized pipe, every 1.2m one Y type connector | Support frame | 80X80X3MM thick iron tube,300X300X12 thick iron foundation board |
| Wire slot and socket | 40*80*1.0mm thick aluminum, every 1.2m install two sockets, GB2.5 square wire. | Wire slot for lamp | 40*80*1.0 aluminum |
| Fans | 14" roof fans | ||
Packing & Delivery
The normal package is wooden box(Size: L 4.1 m*W 1 m*H 1 m). Wooden cases Packing Exporting Standard.
If the container is too higher, we will use PE-film for packing or pack according to the special request of customers.Company Profile
With a history of 18 years, Sanhok group has 418 employees in China. Its branches are all over China, including Guangzhou, Jiangmen, Dongguan, Ningbo and Chongqing. Our brands include Taoli, Yusi, Aoll, sanhok, Xinghuo etc.Our main products include assembly line system, lean pipe joint system, convey roller, roller rail, aluminum, hollow plate, working table. It is mainly used in High-tech product manufacturing industry, household appliance industry, lithium battery industry, warehousing and logistics industry, bathroom industry, electronic industry, LED lamp industry, catering industry, logistics equipment industry.
Now we sincerely hope all friends from all over the world will become our loyal partners and forge ahead.FAQQ1: Usage of the product? A: Air conditioner assembly production line.
Q2: What kind of air conditioner to be produced?
A: Split type, commercial air condition.
Q3: About the delivery time?
A: The delivery will cost about 7-15 days.
Q4: The Production Capacity?
This decide the design of the line. Other products you may be interested in>> Home Page Click Here>>
